额定负荷 Rating DC50V 0.5A 机械寿命 Mechanical Life 5,000 cycles Min
接触电阻 Contact Resistance 50mΩMAX
电气寿命 Electrical Life 5,000 cycles Min
绝缘阻抗 Insulation Resistance 100MΩMIN
适用温度 Ambient Temper.Used -25 ℃ to 85 ℃
耐高压 Withstand Voltage AC 500V(50-60HZ) 1min
适用湿度 Ambient Humidety Used 85% RH
焊接温度 Soldering Temper 260±5°10s
插拔力 Operating Force 3-20N
